Infiniti M45 III (2005-2008) engine controls system pnk computer data lines system can-l Wiring diagram
This page shows the only wiring diagram for the component.engine controls system pnk computer data lines system can-l, which is found in the car Infiniti M45 III (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls system pnk computer data lines system can-l (1 of 1)
ACCEL/ RESUME SWITCH
ASCD BRAKE SWITCH (ON BRAKE PEDAL BRACKET)
ASCD STEERING SWITCH
AVCC 2 MOTOR 1
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
CANCEL SWITCH OFF
CLOSE
COAST/ SET SWITCH
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CRUISE IND (GREEN)
ECM RELAY
ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT SIDE OF DASH)
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM PNK COMPUTER DATA LINES SYSTEM CAN-L WIRE
FUSE 1
FUSE 12
FUSE 14
FUSE 20
FUSE 21
FUSE 77 FUSE 87
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
MAIN SWITCH OFF
MOTOR 2
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RIGHT END OF DASH)
SENSOR 1
SENSOR 2
SET IND
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
THROTTLE POSITION SENSOR
TPS 2 TPS 1
UNIFIED METER CONTROL UNIT
VB VB AVCC 2
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Cruise control circuit, without icc -> ENGINE CONTROLS SYSTEM PNK COMPUTER DATA LINES SYSTEM CAN-L WIRE
