Car Wiring Diagrams for Charging circuit for Infiniti M45 II (2002-2004)

ALTERNATOR BATTERY BLK WIRE BLK/RED WIRE CHARGE WARNING INDICATOR COMBINATION METER ENGINE COMPARTMENT, IN ENGINE ROOM BOX) FUSE 56 FUSE 9 FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH) FUSE, FUSIBLE LINK, RELAY BOX (AT RIGHT SIDE OF GRN WIRE HOT AT ALL TIMES HOT IN ON OR START JOINT CONNECTOR NO 10 (BEHIND UPPER LEFT END OF DASH) 2 2 2 RED WIRE WHT WIRE WHT/RED WIRE YEL/BLK WIRE
