Infiniti M45 II (2002-2004) Ground distribution circuit
Ground distribution circuit (1 of 3)
BLK WIRE
FRONT POWER WINDOW REGULATOR (PASSENGER SIDE), PASSENGER DOOR CONTROL
J/C 5 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
LEFT FRONT FOG LAMP, LEFT FRONT COMBINATION LAMP: PARKING, TURN
LEFT HEADLAMP, RIGHT HEADLAMP, FUSE, FUSIBLE LINK, RELAY BLOCK
UNIT, FRONT DOOR LOCK ACTUATOR (PASSENGER SIDE)
Ground distribution circuit (2 of 3)
ALTERNATOR
BLK WIRE
ICC UNIT (TERMINALS: 19, 20, 46)
J/C 28 (BEHIND UPPER RIGHT SIDE OF DASH, NEAR PASS-THROUGH GROMMET)
J/C 29 (BEHIND UPPER RIGHT SIDE OF DASH, NEAR PASS-THROUGH GROMMET)
REAR WINDOW DEFOGGER
SHIELD WIRE (AIR BAG DIAGNOSIS SENSOR UNIT)
SHIELD WIRE (AIR BAG DIAGNOSIS SENSOR UNIT) (TERMINAL: 40)
SHIELD WIRE (AIR BAG DIAGNOSIS SENSOR UNIT) (TERMINAL: 44)
VDC/TCS/ABS CONTROL UNIT (TERMINALS: 27, 28, 29, 33)
