Car Wiring Diagrams for Electronic muffler circuit for Infiniti M45 II (2002-2004)

1 2 3 4 5 6 IGNITION GROUND TACHOMETER OPEN OUTPUT CLOSE OUTPUT BLK WIRE BLU WIRE DUAL MODE MUFFLER ACTUATOR (AT LEFT REAR OF VEHICLE) DUAL MODE MUFFLER CONTROL UNIT (AT RIGHT SIDE OF LUGGAGE COMPARTMENT) ENGINE CONTROL MODULE (ECM) (BEHIND GLOVE BOX) FUSE 1 FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH) GRN/RED WIRE GRN/YEL WIRE HOT IN ON OR START RED/YEL WIRE TACHOMETER WHT/GRN WIRE
