Infiniti M45 II (2002-2004) up tilt switch down Wiring diagram
This page shows the only wiring diagram for the component.up tilt switch down, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up tilt switch down (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 B+
56 113 68 105 37 GND GND IGNITION BATT DOOR SW (AS)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
CIRCUIT BREAKER 1
CLOSE SLIDE SWITCH 1 2 PPL OPEN
CLOSED DRIVER SIDE FRONT DOOR SWITCH
CLOSED PASSENGER SIDE FRONT DOOR SWITCH
DOOR SW (DR)
FUSE 1
FUSE 3
FUSE BLOCK (J/B) 1 (BEHIND LEFT END OF DASH)
FUSE BLOCK J/B 1 (BEHIND LEFT END END OF DASH)
GND SW GND
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 16 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
J/C 5 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
LT BLU WIRE
LT GRN WIRE
PPL SLIDE OPEN SW TILT DOWN SW IGNITION
RAP OUTPUT
RED WIRE
RED/YEL WIRE
SLIDE CLOSE SW TILT UP SW
SUNROOF MOTOR ASSEMBLY (AT FRONT OF SUN ROOF OPENING)
SUNROOF SWITCH
UP TILT SWITCH DOWN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuit -> UP TILT SWITCH DOWN
