Infiniti M45 II (2002-2004) trunk opener Wiring diagram
This page shows the only wiring diagram for the component.trunk opener, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk opener (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
FUEL LID OPENER ACTUATOR (RIGHT SIDE OF LUGGAGE COMPT)
FUEL LID OPENER SWITCH
FUSE 15
FUSE 3
FUSE BLOCK (J/B) NO. 1 (LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
LT BLU WIRE
PPL
PPL TRUNK OPENER SWITCH
TRUNK LID OPENER ACTUATOR (CENTER REAR OF DECK LID)
TRUNK LID OPENER CANCEL SWITCH
TRUNK LID OPENER RELAY
TRUNK LID OPENER SWITCH
TRUNK LID, FUEL LID OPENER SWITCH
TRUNK OPENER
WHT WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Trunk & fuel door release circuit -> TRUNK OPENER
