Infiniti M45 II (2002-2004) stop tail turn wiring diagram
This page shows the only wiring diagram for the component.stop tail turn, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stop tail turn wiring diagram (1 of 1)
11 14 37 135 142 T/L RLY COMB SW DOOR SW RAP OUT DOOR SW
AUTO OFF
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
COMBI- NATION SWITCH (LIGHTING SWITCH) AUTO OFF
DRIVER SIDE FRONT DOOR SWITCH
FUSE 1
FUSE 17
FUSE 54
FUSE 6
FUSE BLOCK (J/B) NO. 1 (LEFT END OF DASH)
FUSE, FUSIBLE LINK, RELAY BLOCK (J/B) (AT RIGHT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HEADLAMP BATTERY SAVER CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
HEADLIGHTS SYSTEM
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN ON OR START
JOINT CONNECTOR 11 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 13 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 16 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 21 (BEHIND UPPER LEFT SIDE OF DASH)
JOINT CONNECTOR 25 (BEHIND LOWER LEFT SIDE OF DASH, NEAR PASS THROUGH GROMMET)
JOINT CONNECTOR 5 (BEHIND UPPER LEFT SIDE OF DASH)
JOINT CONNECTOR 7 (BEHIND UPPER LEFT SIDE OF DASH)
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP
LEFT REAR SIDE MARKER LAMP
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
PASSENGER SIDE FRONT DOOR SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT REAR SIDE MARKER LAMP
STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
STOP TAIL TURN
T/L SW T/L RLY 2
TAIL LAMP RELAY
TAIL STOP TURN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Exterior lights circuit (1 of 2) -> STOP TAIL TURN
