Infiniti M45 II (2002-2004) steering switch Wiring diagram
This page shows the only wiring diagram for the component.steering switch, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering switch (1 of 1)
1 2 3 PPL
11 12 13 14 27 28 29 30 B+
7 8 9 10 BUS SHIELD
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BOSE SPEAKER AMPLIFIER (CENTER FRONT OF LUGGAGE COMPARTMENT)
BRN WIRE
BRN/WHT WIRE
BUS -
COMBINATION SWITCH (SPIRAL CABLE)
DATA
DISPLAY
FUSIBLE LINK J
GRN WIRE
GRN/RED WIRE
GROUND
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HORN SYSTEM
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT SPEAKER
LEFT REAR DOOR SPEAKER
LT GRN WIRE
MIC + MIC - BUS + BUS -
MULTIFUNCTION SWITCH
NCA WIRE
PPL
RADIO IN RH (-) RADIO IN LH (-) RADIO IN LH (+) RADIO IN RH (+)
RD STRG
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT INSTRUMENT SPEAKER
RIGHT REAR DOOR SPEAKER
SHIELD
STEERING SWITCH
WHT WIRE
WHT/GRN WIRE
WOOFER
YEL WIRE
Go to component -> Radio circuit (2 of 2) -> STEERING SWITCH
