Infiniti M45 II (2002-2004) power window switch illumination Wiring diagrams
This page contains all the electrical diagrams for the component. power window switch illumination, in which he is found in the car Infiniti M45 II (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power window switch illumination (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 PULSE
1 2 3 4 GND DATA OUT
1 3 PNK WIRE
13 12 DATA LINK CONNECTOR (PARTIAL) (UNDER LEFT SIDE OF DASH) PNK WIRE
17 18 27 28 30 31 37 44 67 68 69 105 RX TX K/LESS SIGNAL PNK WIRE
AUTO DOWN
AUTO UP
AUTO UP DRIVER SIDE
AUTO UP PASSENGER SIDE
BAT (C/B)
BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN/WHT WIRE
BRN/YEL WIRE
CIRCUIT BREAKER 1
CIRCUIT BREAKER 2
DOOR LOCK, UNLOCK SWITCH ILLUMINATION
DOOR SW (DR)
DOWN
DRIVER SIDE FRONT DOOR KEY CYLINDER SWITCH
DRIVER SIDE FRONT POWER WINDOW REGULATOR
ENCODER
ENCODER PWR LOCAL DATA LINE
FRONT DOOR SWITCH (DRIVER SIDE)
FRONT DOOR SWITCH (PASSENGER SIDE)
FRONT POWER WINDOW MAIN SWITCH
FULL STROKE FULL STROKE
FUSE 1
FUSE 3
FUSE BLOCK (J/B) 1 (BEHIND LEFT END OF DASH)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 15 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
J/C 16 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
J/C 21 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
J/C 5 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
J/C 8 (BEHIND LOWER LEFT SIDE OF DASH, TAPED TO HARNESS)
LEFT REAR
LIMIT SWITCH
LOCK SWITCH LOCK
LOCK SWITCH UNLOCK SWITCH
LT GRN WIRE
OPEN CLOSED
OTHER FULL CLOSED
PNK WIRE
POWER
POWER WINDOW SWITCH ILLUMINATION
PPL
PPL IIUTX IIURX DOOR SW (AS) K/LESS GND DATA LINE A-3 IGN KEY SWITCH BAT
PPL LIMIT SWITCH DATA LINE A-3 UNLOCK SWITCH LOCK SWITCH DOWN
PPL/WHT WIRE
RED WIRE
RED/YEL WIRE
REMOTE KEYLESS ENTRY RECEIVER
RIGHT REAR
UN LOCK
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit (1 of 2) -> POWER WINDOW SWITCH ILLUMINATION
Wiring diagram power window switch illumination (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PPL LIMIT SWITCH
1 3 2 2 PPL
3 1 PPL
31 34 35 31 33 32 SHIELD AV-ME ME-AV
AUTO DOWN
AUTO UP
AUTO UP FRONT POWER WINDOW SUB- SWITCH
AV, NAVI CONTROL UNIT (OR AV CONTROL UNIT)
BAT (C/B)
BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CONNECTOR USED W/AV, NAVI CONTROL UNIT
DOOR LOCK, UNLOCK SWITCH ILLUMINATION
DOWN
DOWN ENCODER PWR
DOWN FRONT POWER WINDOW REGULATOR (PASSENGER SIDE) ENCODER
FRONT POWER WINDOW SUB SWITCH
FULL CLOSED
FUSE 32
FUSE BLOCK (J/B) 2 (BEHIND RIGHT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
J/C 20 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
J/C 7 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
KEY SWITCH, KEY LOCK SOLENOID (KEY SWITCH)
LEFT REAR DOOR CONTROL UNIT
LEFT REAR POWER WINDOW REGULATOR
LEFT REAR POWER WINDOW SUB SWITCH
LIMIT SWITCH
LT GRN WIRE
NCA WIRE
OTHER
PASSENGER DOOR CONTROL UNIT
POWER WINDOW SWITCH ILLUMINATION
PPL
PPL/WHT WIRE
PULSE
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR POWER WINDOW REGULATOR
RIGHT REAR POWER WINDOW SUB SWITCH
UP LOCAL DATA LINE
W/AV CONTROL UNIT
W/AV, NAVI CONTROL UNIT
WHT WIRE
WHT/RED WIRE
WITH- DRAWN INSERTED
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit (2 of 2) -> POWER WINDOW SWITCH ILLUMINATION
