Infiniti M45 II (2002-2004) lmp fuse lh lamp main sw Wiring diagram
This page shows the only wiring diagram for the component.lmp fuse lh lamp main sw, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lmp fuse lh lamp main sw (1 of 1)
1 2 5 6 14 15 ALT-L
3 4 7 8 IGN LMP FUSE RH LAMP
7 8 PNK WIRE
9 10 11 12 13 16 17 PNK LMP MAIN LMP MAIN WIRE
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
DAYTIME LIGHT CONTROL UNIT (AT LEFT FRONT CORNER OF ENGINE COMPT)
FRONT PASSENGER DOOR SWITCH
FUSE 54
FUSE 55
FUSE 57
FUSE 73
FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK, RELAY BLOCK (J/B) (AT RIGHT SIDE OF ENGINE COMPARTMENT)
HEADLAMP RELAY 1
HEADLAMP RELAY 2
HID
HOT AT ALL TIMES
JOINT CONNECTOR 13 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 20 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
LEFT HEADLAMP
LMP FUSE LH LAMP MAIN SW
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAIN SW GROUND PKB SW
NCA WIRE
PARKING BRAKE SWITCH (ON PARK BRAKE ASSEMBLY)
PNK WIRE
PPL
PPL PPL
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT HEADLAMP
TAIL LAMP RELAY
WHT WIRE
WHT/GRN WIRE
WHT/PPL WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, canada (2 of 3) -> LMP FUSE LH LAMP MAIN SW
