Infiniti M45 II (2002-2004) ign bat gnd Wiring diagrams
This page contains all the electrical diagrams for the component. ign bat gnd, in which he is found in the car Infiniti M45 II (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ign bat gnd (1 of 2)
1 2 3 4 5 6 IGN SW
1 3 PNK WIRE
12 13 PNK WIRE
7 8 9 10 11 12 13 14 BAT
7 8 PNK WIRE
AV CONTROL UNIT (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN/YEL WIRE
COMBINATION SWITCH (LIGHTING SWITCH)
DATA LINK CONNECTOR (DLC)
DOOR SW (DR)
DRIVER DOOR SWITCH
FUSE 1
FUSE 14
FUSE 21
FUSE 3
FUSE 6
FUSE 82
FUSE BLOCK (IN FUSE, FUSIBLE LINK, RELAY BOX)
FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH)
GRN/RED WIRE
HEADLAMP BATTERY SAVER CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
HOT ON
IGN BAT GND
JOINT CONNECTOR 10 (BEHIND UPPER LEFT END OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 11 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 16 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 21 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 5 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 7 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 8 (BEHIND LOWER LEFT SIDE OF DASH)
JOINT CONNECTOR 8 (BEHIND LOWER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 9 (BEHIND LOWER LEFT SIDE OF DASH, TAPED TO HARNESS)
LOW HI PASS
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NAVIGATION SYSTEM
NCA WIRE
OPTICAL SENSOR (ON TOP RIGHT SIDE OF DASH)
PARK AUTO HEAD OFF
PNK PPL WIRE
PNK WIRE
PPL
RAP INPUT
RAP OUTPUT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
T/L RLY OUT 1
W/O NAVIGATION W/ NAVIGATION
WHT/BLK WIRE
WHT/GRN WIRE
WHT/PPL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, canada (1 of 3) -> IGN BAT GND
Wiring diagram ign bat gnd (2 of 2)
1 2 3 4 5 6 IGN SW
1 3 PNK WIRE
12 13 PNK WIRE
7 8 9 10 11 12 13 14 BAT
AV CONTROL UNIT (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN/YEL WIRE
COMBINATION SWITCH (LIGHTING SWITCH)
DATA LINK CONNECTOR (DLC)
DOOR SW (DR)
DRIVER DOOR SWITCH
FUSE 1
FUSE 21
FUSE 3
FUSE 6
FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH)
GRN/RED WIRE
HEADLAMP BATTERY SAVER CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IGN BAT GND
JOINT CONNECTOR 10 (BEHIND UPPER LEFT END OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 11 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 16 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 21 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 5 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 7 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 8 (BEHIND LOWER LEFT SIDE OF DASH)
JOINT CONNECTOR 8 (BEHIND LOWER LEFT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 9 (BEHIND LOWER LEFT SIDE OF DASH, TAPED TO HARNESS)
LOW HI PASS
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NAVIGATION SYSTEM
NCA WIRE
OPTICAL SENSOR (ON TOP RIGHT SIDE OF DASH)
PARK AUTO HEAD OFF
PNK 5 6 WIRE
PNK PPL WIRE
PNK WIRE
PPL
RAP INPUT
RAP OUTPUT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
T/L RLY OUT 1
W/ NAVIGATION
W/O NAVIGATION
WHT/BLK WIRE
WHT/PPL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, usa (1 of 3) -> IGN BAT GND
