Infiniti M45 II (2002-2004) engine compartment, in engine room box) Wiring diagram
This page shows the only wiring diagram for the component.engine compartment, in engine room box), which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine compartment, in engine room box) (1 of 1)
ALTERNATOR
BATTERY
BLK WIRE
BLK/RED WIRE
CHARGE WARNING INDICATOR
COMBINATION METER
ENGINE COMPARTMENT, IN ENGINE ROOM BOX)
FUSE 56
FUSE 9
FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK, RELAY BOX (AT RIGHT SIDE OF
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
JOINT CONNECTOR NO 10 (BEHIND UPPER LEFT END OF DASH) 2 2 2
RED WIRE
WHT WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Charging circuit -> ENGINE COMPARTMENT, IN ENGINE ROOM BOX)
