Infiniti M45 II (2002-2004) brake booster Wiring diagram

1 2 3 4 5 6 IGNITION 4 4 5 5 J/C 7 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS) 89 113 GND-A TVOO ACCELERATE/ RESUME SWITCH AIR VALVE ASCD PUMP (AT RIGHT REAR CORNER OF ENGINE COMPARTMENT) BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BOOST SOLENOID BRAKE BOOSTER BRN WIRE BRN/WHT WIRE CAN H GND CAN L CANCEL SWITCH COAST/ SET SWITCH COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CRUISE GND-S TVO SAFTY VENT VACUUM MOTOR DISTANCE SWITCH ENGINE CONTROL MODULE (BEHIND GLOVE BOX) FUSE 1 FUSE BLOCK (J/B) 1 (BEHIND LEFT END OF DASH) GRN WIRE GRN/ORG WIRE GRN/YEL WIRE GRY/BLU WIRE HOT IN ON OR START ICC BRAKE HOLD RELAY (AT LEFT REAR OF ENGINE COMPARTMENT) ICC SENSOR (BEHIND CENTER OF FRONT BUMPER) ICC STEERING SWITCH ICC UNIT (ON RIGHT SIDE OF LUGGAGE COMPARTMENT) ICC WARNING CHIME (BELOW LOWER LEFT SIDE OF DASH) J/C 1 (BEHIND UPPER LEFT END OF DASH, TAPED TO HARNESS) J/C 25 (BEHIND LOWER LEFT SIDE OF DASH, NEAR PASS-THROUGH GROMMET) 3 3 3 J/C 3 (BEHIND UPPER LEFT END OF DASH, TAPED TO HARNESS) J/C 30 (BEHIND UPPER RIGHT SIDE OF DASH, NEAR PASS-THROUGH GROMMET) 1 1 NCA WIRE ON/OFF SWITCH ORG/ WIRE ORG/GRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELEASE VALVE STOPLAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) STRG SIG T-RLY STRG GND OD-CANCEL VACUUM MOTOR WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
