Infiniti M45 II (2002-2004) auto anti-dazzling mirror Wiring diagram
This page shows the only wiring diagram for the component.auto anti-dazzling mirror, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto anti-dazzling mirror (1 of 1)
AUTO ANTI-DAZZLING MIRROR
BACK-UP LAMP RELAY (AT LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN WIRE
BRN/YEL WIRE
CHANGE OVER SWITCH
DOOR MIRROR ACTUATOR
DOOR MIRROR REMOTE CONTROL SWITCH
DRIVER SIDE DOOR MIRROR
DRIVER SIDE DOOR MIRROR CONTROL UNIT
FUSE 3
FUSE 8
FUSE 9
FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH)
GND GND
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
JOINT CONNECTOR 10 (BEHIND UPPER LEFT END OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 15 (BEHIND UPPER RIGHT SIDE OF DASH, TAPED TO HARNESS)
JOINT CONNECTOR 5 (BEHIND UPPER LEFT SIDE OF DASH, TAPED TO HARNESS)
LT BLU WIRE
LT GRN/RED WIRE
MEMORY SYSTEM
MIRROR SW DWN SELECT SW LT SELECT SW RT SET SW
MIRROR SWITCH
OEC (-) OEC (+)
ORG/ WIRE
ORG/BLU WIRE
PASSENGER SIDE DOOR MIRROR ACTUATOR
PASSENGER SIDE DOOR MIRROR CONTROL UNIT
PNK/BLK WIRE
PNK/BLU WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REV-LAMP SW
TRANSMISSION CONTROL MODULE (TCM) (BEHIND GLOVE BOX)
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Reverse interlock circuit -> AUTO ANTI-DAZZLING MIRROR
