Infiniti M45 II (2002-2004) 7 10 11 13 14 bat rap input Wiring diagram
This page shows the only wiring diagram for the component.7 10 11 13 14 bat rap input, which is found in the car Infiniti M45 II (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 7 10 11 13 14 bat rap input (1 of 1)
1 4 5 6 IGN SW
7 10 11 13 14 BAT RAP INPUT
AUTO OFF
AV CONTROL UNIT (W/O NAVI) (BEHIND CENTER OF DASH)
AV, NAVI CONTROL UNIT (W/ NAVI) (AT FRONT CENTER OF LUGGAGE COMPT)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
COMBINATION METER
COMBINATION SWITCH LIGHT SWITCH
DIODE (BEHIND UPPER LEFT SIDE OF DASH)
DOOR SW (DR)
DRIVER FRONT DOOR SWITCH
FRONT INTERIOR LAMP
FUSE 1
FUSE 54
FUSE 6
FUSE 8
FUSE 9
FUSE, FUSIBLE LINK, RELAY BLOCK (J/B) (AT RIGHT SIDE OF ENGINE COMPT)
GRN WIRE
GROUND
HEADLAMP BATTERY SAVER CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR START FUSE BLOCK (J/B) NO. 1 (BEHIND LEFT END OF DASH)
ILLUMINATION
JOINT CONNECTOR 10 (BEHIND UPPER LEFT END OF DASH)
JOINT CONNECTOR 11 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 16 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 21 (BEHIND UPPPER LEFT SIDE OF DASH)
JOINT CONNECTOR 5 (BEHIND UPPER LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
RAP OUTPUT
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH
T/L SW 1 T/L RLY OUT 1
T/L SW 2 T/L RLY OUT 2
TAILLIGHT RELAY
TAL/L RLY COMB SW (AUTO) DOOR SW (AS)
UNIFIED METER CONTROL UNIT
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> 7 10 11 13 14 BAT RAP INPUT
