Infiniti M37 IV (2010-2014) Cooling fan circuit

1 2 3 PPL 114 113 107 105 112 PNK WIRE 71 84 TW BATTERY TERMINAL W/ FUSIBLE LINK BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN CONTROL MODULE (BEHIND RADIATOR) COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR) COOLING FAN MOTOR 2 (BEHIND RIGHT SIDE OF RADIATOR) COOLING FAN RELAY 1 (IN FUSE, FUSIBLE LINK, RELAY BOX) ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPARTMENT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE) FUSE 42 FUSIBLE LINK D FUSIBLE LINK HOLDER 1 FUSIBLE LINK O GRN WIRE HOT AT ALL TIMES IGNITION RELAY LT BLU WIRE LT GRN WIRE NCA WIRE PCB HARNESS PDPRES GNDA-PDPRES FTPRES PPL PNK PPL WIRE PPL RED WIRE REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPARTMENT) TAN WIRE WHT WIRE
