Infiniti M37 IV (2010-2014) stop lamp sw 2 Wiring diagram
This page shows the only wiring diagram for the component.stop lamp sw 2, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp sw 2 (1 of 1)
14 15 12 23 PNK WIRE
25 21 NATS ANTENNA AMP NATS ANTENNA AMP PNK WIRE
3.7L 5.6L
70 57 BAT FL BAT FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
CAN COMM
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DATA
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPT)
FUSE 11
FUSE 51
FUSE 7
FUSE 9 DASH)
FUSE BLOCK (J/B) (BEHIND LEFT END OF
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK L
GRN WIRE
HOT AT ALL TIMES
NATS ANTENNA AMPLIFIER
PCB HARNESS
PNK CAN-L WIRE
PNK CLK WIRE
PNK WIRE
PPL
RED WIRE
SECURITY IND
SECURITY IND CONT
STOP LAMP SW 2
UNIFIED METER CONTROL UNIT
WHT WIRE
Go to component -> Immobilizer circuit -> STOP LAMP SW 2
