Infiniti M37 IV (2010-2014) starting/ charging ppl system Wiring diagram

408 409 PPL 2 A/C AUTO AMP A/T ASSEMBLY A/T FLUID TEMPERATURE SENSOR A/T SHIFT SELECTOR ANTI- INTERLOCK SOLENOID VALVE ATF PRESSURE SENSOR AUTO MANUAL SHIFT LOCK UNIT MODE SELECT SWITCH BLK WIRE BLU WIRE BRAKE SOLENOID VALVE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) DIRECT CLUTCH SOLENOID VALVE DRIVE MODE SELECT SWITCH FRONT BRAKE SOLENOID VALVE FUSE 4 FUSE 9 FUSE BLOCK (J/B) (BEHIND GRN WIRE HIGH, LOW REVERSE CLUTCH SOLENOID HOT AT ALL TIMES HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) FUSE 36 HOT IN ON OR START ILL INPUT CLUTCH SOLENOID VALVE INPUT SPEED SENSOR 1 INPUT SPEED SENSOR 2 JOINT CONNECTOR LEFT END OF DASH) LINE PRESSURE SOLENOID LT BLU WIRE LT GRN WIRE NCA WIRE OUTPUT SPEED SENSOR 2 3 PADDLE SHIFTER (SHIFT DOWN) (IF EQUIPPED) PADDLE SHIFTER (SHIFT-UP) (IF EQUIPPED) PCB HARNESS PNK WIRE POSITION SELECT SWITCH PPL RED WIRE REV LAMP RLY CAN-L START RLY GND SHIFT INTERLOCK SYSTEM SNOW ECO SPORT STANDARD STARTING/ CHARGING PPL SYSTEM TAN WIRE TCM (TRANSMISSION CONTROL MODULE) TORQUE CONVERTER CLUTCH SOLENOID VALVE TRANSMISSION RANGE SWITCH TRANSMISSION RANGE SWITCH ASSEMBLY UP DN VALVE VALVE LOW BRAKE SOLENOID VALVE VIGN BATT CAN-H K LINE GND VIGN WHT WIRE YEL WIRE
