Infiniti M37 IV (2010-2014) sliding front lifting motor motor Wiring diagram
This page shows the only wiring diagram for the component.sliding front lifting motor motor, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sliding front lifting motor motor (1 of 1)
BACKWARD
BAT (F/L)
BAT FUSE
BCM (BODY CONTROL MODULE) (BEHIND LEFT SIDE OF DASH)
BK FD RECLINING SWITCH
BK UP SLIDING FRONT SWITCH LIFTING SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
DN UP
DN UP DN REAR LIFTING SWITCH
FD BK
FORWARD/
FUSE 11
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK L
GRN WIRE
HOT AT ALL TIMES
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
PASSENGER SIDE FRONT SEAT
PASSENGER SIDE POWER SEAT SWITCH
POWER WINDOW POWER SUPPLY (BAT)
PPL (OR PNK) WIRE
REAR LIFTING MOTOR
RECLINING MOTOR
RED WIRE
SLIDING FRONT LIFTING MOTOR MOTOR
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> SLIDING FRONT LIFTING MOTOR MOTOR
