Infiniti M37 IV (2010-2014) rear sunshade motor Wiring diagram
This page shows the only wiring diagram for the component.rear sunshade motor, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear sunshade motor (1 of 1)
1 2 3 4 5 6 +IG GND
7 8 REAR SUNSHADE OPEN REAR SUNSHADE CLOSE
A/T ASSEMBLY
BACKUP LAMP RELAY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
FUSE 3
FUSE BEHIND LEFT END OF DASH)
FUSE BLOCK (J/B)
GRN WIRE
HOT IN ON OR START
JOINT CONNECTOR
LT BLU WIRE
LT GRN WIRE
PCB HARNESS
PNK 3 6 WIRE
PNK REVERSE WIRE
PNK WIRE
REAR SUNSHADE CONTROL UNIT
REAR SUNSHADE MOTOR
RED WIRE
RED/WHT WIRE
REV LAMP RLY
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
TWIN REAR SUNSHADE SWITCH SWITCH
UP/DOWN SW
WHT WIRE
Go to component -> Rear window sun shade circuit -> REAR SUNSHADE MOTOR
