Infiniti M37 IV (2010-2014) ppl pnk hsv-r can-l hsg-r ps-r Wiring diagram
This page shows the only wiring diagram for the component.ppl pnk hsv-r can-l hsg-r ps-r, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl pnk hsv-r can-l hsg-r ps-r (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 IGN PSG-R SW PSV-R
15 14 PNK CAN-L CAN-H WIRE
2 1 23 12 IGN SIGNAL BAT PWR SUP GROUND GROUND
2 1 7 8 PNK CAN-L CAN-H GND IGN WIRE
32 33 SMR-2 (+)
34 35 SMR-1 (+)
36 37 SML-2 (-)
38 39 40 SML-1 (-)
AFS CONTROL UNIT (BEHIND LEFT END OF DASH)
AFS OFF IND
AMDS-L
AMDS-R
AMPLIFIER AMPLIFIER
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE (LEFT END OF DASH)
FUSE 46
FUSE BLOCK (J/B) (BEHIND
FUSE FUSE
GRN WIRE
GRY WIRE
HEIGHT SENSOR
HOT AT ALL TIMES
HOT IN ON OR START
LEFT HEADLAMP RIGHT HEADLAMP AIMING MOTOR AIMING MOTOR
LEFT HEADLAMP SWIVEL ACTUATOR
LT BLU WIRE
LT GRN WIRE
METER CONTROL SWITCH (AFS SWITCH)
NCA WIRE
ORG/ WIRE
PCB HARNESS
PNK WIRE
PPL
PPL PNK HSV-R CAN-L HSG-R PS-R WIRE
PSG-L HS-R PS-L CAN-H
PSV-L GND 25 26 27 28 29 30 31
RED WIRE
RIGHT HEADLAMP SWIVEL ACTUATOR
SML-1 (-)
SML-2 (-)
SMR-1 (+)
SMR-2 (+)
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Adaptive front lighting circuit -> PPL PNK HSV-R CAN-L HSG-R PS-R WIRE
