Infiniti M37 IV (2010-2014) pcb harness 7 8 gnd ign can-h can-l pnk system Wiring diagram
This page shows the only wiring diagram for the component.pcb harness 7 8 gnd ign can-h can-l pnk system, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pcb harness 7 8 gnd ign can-h can-l pnk system (1 of 1)
3 2 COMPUTER BUS-H BUS-L DATA LINES SYSTEM
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (LEFT REAR OF ENGINE COMPT)
ADAS CONTROL UNIT (W/ ICC) (REAR OF VEHICLE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA CAN H LINES SYSTEM
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
FUSE 46
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR
FUSIBLE LINK M
FUSIBLE LINK N
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN/PWR
LEFT REAR WHEEL SENSOR (ON LEFT REAR WHEEL HUB ASSEMBLY)
LT BLU WIRE
LT GRN WIRE
OF ENGINE COMPT)
ORG/ WIRE
OUT SIG
PCB HARNESS
PCB HARNESS 7 8 GND IGN CAN-H CAN-L PNK SYSTEM WIRE
PNK WIRE
PPL
PPL VAC SEN(PWR)
RED WIRE
RIGHT REAR WHEEL SENSOR (ON RIGHT REAR WHEEL HUB ASSEMBLY)
RR-LH SEN(SIG) RR-LH SEN(PWR) FR-RH SEN(SIG) FR-RH SEN(PWR)
SHIELD
SHIELD VAC SEN(GND)
STEERING ANGLE SENSOR (ON STEERING COLUMN)
TRIPLE SWITCH VDC OFF SWITCH
VAC SEN(SIG)
VACUUM SENSOR (BELOW BRAKE MASTER CYLINDER)
VDC OFF SW
WHT WIRE
YAW RATE/ SIDE/DECEL G SENSOR (UNDER CENTER CONSOLE)
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> PCB HARNESS 7 8 GND IGN CAN-H CAN-L PNK SYSTEM WIRE
