Infiniti M37 IV (2010-2014) passenger's side door mirror Wiring diagram
This page shows the only wiring diagram for the component.passenger's side door mirror, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side door mirror (1 of 1)
AV COMM (H) COMPUTER DATA LINES SYSTEM AV COMM (L)
AV COMM (L) COMPUTER DATA LINES SYSTEM AV COMM (H)
AV CONTROL UNIT (BEHIND CENTER OF DASH)
BAT (F/L)
BCM (BODY CONTROL MODULE) (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
CAN-H
COMPUTER DATA LINES SYSTEM
CONDENSER
DRIVER SIDE DOOR MIRROR
FUSE 11
FUSE 13
FUSE 14 FUSE 15
FUSE 3
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSIBLE LINK E
FUSIBLE LINK HOLDER (RIGH SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MULTI-FUNCTION SWITCH (REAR WINDOW DEFOGGER SWITCH)
NCA WIRE
PASSENGER'S SIDE DOOR MIRROR
PNK CAN-L WIRE
PNK WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
RED WIRE
RR WINDOW DEFG RLY 57 67 BAT (FUSE) GND
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
Go to component -> Defoggers circuit -> PASSENGER'S SIDE DOOR MIRROR
