Infiniti M37 IV (2010-2014) passenger side door mirror upwd close Wiring diagram
This page shows the only wiring diagram for the component.passenger side door mirror upwd close, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side door mirror upwd close (1 of 1)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
BWD FWD
CLOSE
DEFOGGER SYSTEM
DNWD
DRIVER SIDE DOOR MIRROR UPWD DNWD OPEN
GRN WIRE
GRY WIRE
LHWD
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER SIDE DOOR MIRROR UPWD CLOSE
PCB HARNESS
PNK WIRE
PPL
PPL PNK WIRE
RED WIRE
RHWD
TAN WIRE
TELESCOPIC MOTOR
TELESCOPIC SENSOR
TELESCOPIC SW (BWD) MIRR SENS (LH HORIZONTAL)
TILT DOWN UP SENSOR
TILT MOTOR
TILT TELESCOPIC SWITCH SWITCH
UP DN FWD BWD
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (1 of 3) -> PASSENGER SIDE DOOR MIRROR UPWD CLOSE
