Infiniti M37 IV (2010-2014) inj 3 ing 6 batt temp ppl Wiring diagram
This page shows the only wiring diagram for the component.inj 3 ing 6 batt temp ppl, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inj 3 ing 6 batt temp ppl (1 of 1)
123 124 125 126 127 128 GND GND VBR BNC SW GND GND
AF+2 AF-2
ASCD SW FTPRES PNK WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CAN L
CAN-H
CDCV BRAKE PNK WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM PPL K-LINE
CRUISE CONTROL SYSTEM
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ELECTRONIC POWER STEERING SYSTEM
GND ASCD SW NEUT-H TACHO
GNDA CURSEN GNDA PHS 1/PS
GRN WIRE
GRY WIRE
HOT IN ON OR START FUSE BLOCK (J/B) FUSE 3 (BEHIND LEFT END OF DASH)
ICC BRAKE SWITCH (W/ ICC) ASCD BRAKE SWITCH (W/O ICC) (ON BRAKE PEDAL BRACKET)
INJ 1 INJ 4 CURSEN GNDA,PHS 2 BATT
INJ 3 ING 6 BATT TEMP PPL
INJ-2 INJ-5 PSPRES
JOINT CONNECTOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PCB HARNESS
PDPRES TF PNK WIRE
PNK WIRE
PPL
PPL PNK GNDA PDPRES/FTPRES WIRE
PPL/ PPL/ PPL/
RED WIRE
SENSOR 1
SENSOR 2 ACCELERATOR PEDAL POSITION (APP) SENSOR (ON ACCELERATOR PEDAL BRACKET)
SHIELD
START RLY
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE) A/T ASSEMBLY
TW GNDA-KNK SHIELD
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.7l (5 of 6) -> INJ 3 ING 6 BATT TEMP PPL
