Infiniti M37 IV (2010-2014) hot in on or start fuse 46 Wiring diagram
This page shows the only wiring diagram for the component.hot in on or start fuse 46, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on or start fuse 46 (1 of 1)
5.6L 3.7L
6 7 GND
BLK WIRE
BLU WIRE
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPT)
EPS SOL-
GRN WIRE
GRY WIRE
HOT IN ON OR START FUSE 46
IGN
LT GRN WIRE
PCB HARNESS
PNK CAN-L WIRE
POWER STEERING CONTROL UNIT (BEHIND RIGHT SIDE OF DASH)
POWER STEERING SOLENOID VALVE
PPL
PPL ENG TACHO
VEHICLE SPEED
Go to component -> Electronic power steering circuit, without 4was -> HOT IN ON OR START FUSE 46
