Infiniti M37 IV (2010-2014) fuse 56 fuse 55 Wiring diagram
This page shows the only wiring diagram for the component.fuse 56 fuse 55, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 56 fuse 55 (1 of 1)
39 PNK WIRE
BLK WIRE
BLU WIRE
DAYTIME RUNNING LIGHT RELAY (IN FUSE, FUSIBLE LINK, RELAY BOX)
FRONT FOG LAMP RELAY
FUSE 51
FUSE 54
FUSE 56 FUSE 55
FUSE 57
FUSE 59
GRN WIRE
HEADLAMP
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HID CONT
HIGHBEAM HEADLAMP SOLENOID
HIGHBEAM SOLENOID
HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK FUSE 38
HOT AT ALL TIMES FUSIBLE LINK HOLDER FUSIBLE LINK F
HOT AT ALL TIMES IPDM E/R (INTELLIGENT POWER DISTRIBUTION
LEFT FRONT COMBINATION LAMP
LEFT FRONT FOG LAMP
LT BLU WIRE
MODULE FUSE 50 ENGINE ROOM) (RIGHT REAR OF ENGINE COMPT)
ORG/ WIRE
PNK (OR WIRE
PNK 1 2 WIRE
PNK WIRE
RED WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT FOG LAMP
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit (2 of 2) -> FUSE 56 FUSE 55
