Infiniti M37 IV (2010-2014) fuse 31 Wiring diagrams

This page contains all the electrical diagrams for the component. fuse 31, in which he is found in the car Infiniti M37 IV (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram fuse 31 (1 of 4)

Wiring diagram fuse 31 for Infiniti M37 IV (2010-2014) (1 of 4)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BUZZER COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 11 FUSE 31 FUSE 4 FUSE 7 FUSE 9 FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HORN HORN (HIGH) HORN RELAY (IN FUSE, FUSIBLE LINK BOX) HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR) LT GRN WIRE PCB HARNESS PNK 9 10 WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR) SECURITY IND STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) TAN WIRE UNIFIED METER CONTROL UNIT VEHICLE SECURITY VEHICLE SECURITY HORN RELAY (IN FUSE, FUSIBLE LINK, RELAY BOX) WHT WIRE YEL WIRE

Go to component -> Forced entry circuit (4 of 4) -> FUSE 31

Wiring diagram fuse 31 (2 of 4)

Wiring diagram fuse 31 for Infiniti M37 IV (2010-2014) (2 of 4)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM FUSE 31 FUSE 50 FUSE 51 FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HORN (HIGH) HORN RELAY (IN FUSE, FUSIBLE LINK BLOCK) HORN SWITCH HOT AT ALL TIMES LT GRN WIRE NCA WIRE PNK WIRE WHT WIRE

Go to component -> Horn circuit -> FUSE 31

Wiring diagram fuse 31 (3 of 4)

Wiring diagram fuse 31 for Infiniti M37 IV (2010-2014) (3 of 4)

Get access

ANTI-LOCK BRAKES SYSTEM BATTERY BATTERY TERMINAL W/ FUSIBLE LINK BLK WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BODY COMPUTER SYSTEM MEMORY SYSTEM BODY COMPUTER, MEMORY& SEATS SYSTEMS BRN WIRE DOOR LOCKS, ANTI-THEFT SYSTEMS ECM RELAY ELECTRONIC POWER STEERING SYSTEM ENGINE CONTROLS SYSTEM ENGINE CONTROLS, ANTI-THEFT SYSTEM ENGINE HEADLIGHTS CONTROLS SYSTEM SYSTEM FUSE FUSE 11 FUSE 8 FUSE 31 FUSE 34 FUSIBLE LINK J FUSE 37 FUSE 36 FUSE 48 FUSE 5 FUSE 51 FUSE 6 FUSE 7 FUSE 9 FUSE FUSE 33 FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK G (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK A FUSIBLE LINK B FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK F FUSIBLE LINK H FUSIBLE LINK I (5.6L) FUSE 38 FUSIBLE LINK K FUSIBLE LINK L FUSIBLE LINK M FUSIBLE LINK N GRN WIRE GRY WIRE IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE LT GRN WIRE NAVIGATION, SOUND SYSTEMS NCA WIRE OPTIONAL CONNECTOR ORG/ WIRE PASSIVE RESTRAINTS SYSTEM PNK WIRE PPL RED WIRE SEATS SYSTEM SOUNDS, NAVIGATION SYSTEMS STARTER RELAY STARTING/ CHARGING SYSTEM STARTING/CHARGING, ANTI-THEFT, HORNS SYSTEMS STEERING LOCK RELAY THROTTLE CONTROL MOTOR RELAY TO ACCESSORY RELAY (DIAGRAM 2 OF 3) TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 3) TO FUSIBLE LINK HOLDER 1, 2 (DIAGRAM 2 OF 3) TO IGNITION RELAY (DIAGRAM 3 OF 3) TO IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) (DIAGRAM 3 OF 3) TO PUSH BUTTON IGNITION SWITCH (DIAGRAM 2 OF 3) TRANSMISSIONS ENGINE SYSTEM CONTROLS SYSTEM TRANSMISSIONS SYSTEM WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (1 of 3) -> FUSE 31
