Infiniti M37 IV (2010-2014) driver side climate controlled seat switch illumination Wiring diagram
This page shows the only wiring diagram for the component.driver side climate controlled seat switch illumination, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side climate controlled seat switch illumination (1 of 1)
A/T SHIFT SELECTOR ILLUMINATION
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CIGARETTE LIGHTER SOCKET ILLUMINATION
CLOCK ILL (+)
COMBINATION SWITCH (SPIRAL CABLE)
DRIVE MODE SELECT SWITCH (ILLUMI- NATION)
DRIVER SIDE CLIMATE CONTROLLED SEAT SWITCH ILLUMINATION
DRIVER SIDE HEATED SEAT SWITCH (ILLUMINATION)
GLOVE BOX LAMP)
GRN WIRE
ILL
INDIRECT CENTER CONSOLE MAP LAMP (ILLUMI- NATION)
METER CONTROL SWITCH (ILLUMI- NATION)
MULTI ILL FUNCTION SWITCH (ILLUMI- NATION) CONT
NCA WIRE
ORG/ WIRE
PCB HARNESS
PNK WIRE
RED WIRE
RIGHT REAR ASHTRAY ILLUMINATION
SEAT MEMORY SWITCH (ILLUMI- NATION)
STEERING SWITCH ILLUMINATION
TAN WIRE
W/ CLIMATE CONTROLLED SEAT
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> DRIVER SIDE CLIMATE CONTROLLED SEAT SWITCH ILLUMINATION
