Infiniti M37 IV (2010-2014) 5 3 4 1 2 6 ign its comm-l its comm-h rh/ lh sw sig gnd bsw/ bsi ind Wiring diagram

14 15 16 CAN-H CAN-L IGNITION 25 15 CAN-H CAN-L PNK WIRE 3 1 4 6 IBA OFF SW WARNING SYS SW WARNING SYS ON IND GND 39 40 CAN-H CAN-L PNK WIRE 5 3 4 1 2 6 IGN ITS COMM-L ITS COMM-H RH/ LH SW SIG GND BSW/ BSI IND 5 4 3 6 2 IGN ITS COMM-H ITS COMM-L BSW/ BSI IND GND A/T ASSEMBLY ABS ACTUATOR, ELECTRIC UNIT (LEFT REAR OF ENGINE COMPT) ADAS CONTROL UNIT (REAR OF VEHICLE) BCM (BODY COMPUTER MODULE) (BEHIND LEFT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 46 DISTRIBUTION ROOM (IPDM E/R) MODULE ENGINE (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE 6 HOT IN ON OR START IBA OFF SWITCH INDICATOR JOINT CONNECTOR LEFT BSW/BSI INDICATOR LEFT SIDE RADAR LT GRN WIRE NCA WIRE ORG/ WIRE PCB HARNESS PNK WIRE RED WIRE RIGHT BSW/BSI INDICATOR RIGHT SIDE RADAR TCM (TRANSMISSION CONTROL MODULE) TRIPLE SWITCH WARNING BUZZER WARNING SYSTEMS SWITCH WHT WIRE YEL WIRE
