Infiniti M37 IV (2010-2014) 2 1 am-fm main amp on sig Wiring diagram
This page shows the only wiring diagram for the component.2 1 am-fm main amp on sig, which is found in the car Infiniti M37 IV (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 1 am-fm main amp on sig (1 of 1)
1 2 3 137 138 139 ALTGR AM-FM MAIN ALTGR
132 133 134 135 136 USB GND V BUS SIG
2 1 AM-FM MAIN AMP ON SIG
ANTENNA
ANTENNA AMPLIFIER
AV COMM (H)
AV COMM (L)
AV CONTROL UNIT (BEHIND CENTER OF DASH)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMM
COMPUTER DATA LINES SYSTEM
EJECT SIG
GRN WIRE
L SOUND SIG (+)
LH SATELLITE SOUND SIG (-) RH SATELLITE SOUND SIG (-) SHIELD SHIELD
LT BLU WIRE
LT GRN WIRE
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PCB HARNESS
PNK WIRE
PPL
R SOUND SIG (+)
RED WIRE
REQUEST
REQUEST COMM
SATELLITE RADIO ANTENNA
SATELLITE RADIO TUNER
SHIELD
SHIELD PNK SHIELD TEL VOICE SIG (+) TEL VOICE SIG (-) WIRE
SHIELD SHIELD
SW GND
TAN WIRE
USB CONNECTOR
USB D- SIG USB D+ SIG SHIELD SHIELD
VEHICLE SPD
VEHICLE SPD PARKING BRAKE REVERSE IGN DISK EJECT SIG PPL
WHT WIRE
WINDOW ANTENNA (MAIN)
WINDOW ANTENNA (SUB)
YEL WIRE
Go to component -> Radio circuit, without navigation (4 of 4) -> 2 1 AM-FM MAIN AMP ON SIG
