Infiniti J30 I (1992-1997) Power window circuit

19 20 ILLUMINATION 21 22 23 24 25 26 27 28 29 30 BAT GND UP SW DOWN SW UP DOWN SW COM U/D SIGNAL 21 22 23 24 25 26 27 BAT GND 28 29 30 U/D SIGNAL BLK WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE CIRCUIT BREAKER DATA SIG (RIGHT REAR) DATA SIG (LEFT REAR) DATA SIG (RIGHT FRONT) DN PWR SRCE FUSE 15 FUSE 16 FUSE 27 FUSE 20 FUSE BLOCK (LEFT KICK PANEL) GRN WIRE GRN/RED (OR GRN/WHT) WIRE GRN/RED WIRE GRN/WHT WIRE GROUND PWR SRCE (BAT) HOT AT ALL TIMES HOT IN ON OR START J/C 10 (RIGHT SIDE OF DASH) JC-8 (LEFT SIDE OF I/P) LEFT FRONT POWER WINDOW REG- ULATOR LEFT REAR POWER WINDOW AMP (LEFT REAR DOOR) LEFT REAR POWER WINDOW REGULATOR LEFT REAR POWER WINDOW SWITCH LT GRN/RED WIRE NCA WIRE ORG/BLK WIRE ORG/BLU WIRE P/W LOCK PNK/BLK WIRE POWER WINDOW MAIN SWITCH PWR SRCE (IGNITON) PWR WIN LOCK SIG RED WIRE RED/BLK WIRE RIGHT FRONT POWER WINDOW AMP (RIGHT FRONT DOOR) RIGHT FRONT POWER WINDOW REGULATOR RIGHT FRONT POWER WINDOW SWITCH RIGHT REAR POWER WINDOW AMP (RIGHT REAR DOOR) RIGHT REAR POWER WINDOW REGULATOR RIGHT REAR POWER WINDOW SWITCH SMJ CONNECTOR (LEFT SIDE KICK PANEL) SMJ CONNECTOR (RIGHT SIDE KICK PANEL) UP PWR SRCE UP SW DOWN SW UP DN SW COM U/D SIGNAL UP SW DOWN SW UP DOWN SW COM WHT/BLU WIRE WHT/PPL WIRE WHT/RED WIRE
