Infiniti I35 II (2000-2004) Anti-lock brake circuits, without dynamic stability control

ABS IND. ABS SILA METER OUT ABS/TCS CONTROL UNIT (UNDER DRIVER'S SEAT) ACTUATOR BLK WIRE BLS BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE COMBINATION METER CONTROL UNIT) DATA LINK COMPUTER SYSTEM DATA LINK CONNECTOR (LOWER DASH OF DASH) DIAG-K DIAG-L FL IN FL OUT FR IN FR OUT FUSE 2 FUSE 30 FUSE 31 FUSE BLOCK (BEHIND LEFT SIDE OF DASH) FUSE D FUSE E FUSE, FUSIBLE LINK BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN LEFT FRONT WHEEL SENSOR LEFT REAR WHEEL SENSOR LT BLU WIRE METER OUT MOTOR MON MOTOR RELAY ORG/ WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ACT RELAY MON RELAY UNIT RIGHT FRONT WHEEL SENSOR RIGHT REAR WHEEL SENSOR RL IN RL OUT RR IN RR OUT RR SS (+) GND RR SS FR SS GND FR SS FL SS GND FL SS RL SS GND RL SS SLIP IND SLIP SILA CAN-L CAN-H TSC SW SOLENOID VALVE RELAY STOPLIGHT SWITCH (ON BRAKE PEDAL BRACKET) TCS IND TCS OFF SILA TCS ON/OFF SWITCH UNIFIED METER CONTROL UNIT WHT WIRE WHT/BLK WIRE YEL WIRE
