Infiniti G37 IV facelift (2006-2013) voice/ volume menu down down telephone Wiring diagram
This page shows the only wiring diagram for the component.voice/ volume menu down down telephone, which is found in the car Infiniti G37 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram voice/ volume menu down down telephone (1 of 1)
28 29 SHIELD
AV COMM (H)
AV COMM (L)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN)
COMM
COMPUTER DATA LINES SYSTEM
CONTROL SIG
DISPLAY UNIT
GRN WIRE
GRY WIRE
IGN
ILLUM
IMAGE GND
IMAGE SIG
INVERTER GND
INVERTER VCC
LT BLU WIRE
LT GRN WIRE
MENU SOURCE UP
MICROPHONE
NCA WIRE
ORG/ WIRE
PNK PPL WIRE
PNK SHIELD PPL WIRE
PNK SHIELD WIRE
PNK WIRE
PPL
RED WIRE
RETRACTABLE HARD TOP CONTROL UNIT (BEHIND LEFT REAR SIDE FINISHER)
RGB AREA SIG
RGB SIG
RGB SYNC
ROOF SIG
SHIELD
SHIELD SHIELD
SIG
SIG GND
SIGNAL VCC
STEERING SWITCH
TAN WIRE
TEL ADAPTER UNIT
TEL ANTENNA
TELEPHONE VOLUME END UP
VAHICLE SPD
VCC
VOICE SIG
VOICE/ VOLUME MENU DOWN DOWN TELEPHONE
WHT WIRE
YEL WIRE
Go to component -> Bose radio circuit, convertible without navigation (2 of 4) -> VOICE/ VOLUME MENU DOWN DOWN TELEPHONE
