Infiniti G37 IV facelift (2006-2013) thermistor output Wiring diagram
This page shows the only wiring diagram for the component.thermistor output, which is found in the car Infiniti G37 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thermistor output (1 of 1)
17 18 HEAT SENSOR
70 71 HEAT SENSOR
A/T W/O MEMORY
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
DRIVER SIDE FRONT SEAT
DRIVER SIDE HEATED SEAT SWITCH
FUSE 3
FUSE 35
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK
GRN WIRE
GRY WIRE
HEATED SEAT CONTROL UNIT
HEATED SEAT RELAY (BEHIND CENTER OF DASH)
HEATER
HEATER SW
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR
LT BLU WIRE
LT GRN WIRE
M/T
M/T, A/T W/ MEMORY
MAIN HEATER SEAT BACK HEATER
MAIN SUB- HEATER HEATER
NCA WIRE
PASSENGER SIDE FRONT SEAT
PASSENGER SIDE HEATED SEAT SWITCH
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SEAT CUSHION HEATER
SUB HEATER
TAN WIRE
THERMISTOR INPUT
THERMISTOR OUTPUT
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit, sedan -> THERMISTOR OUTPUT
