Infiniti G37 IV facelift (2006-2013) step lamp Wiring diagram
This page shows the only wiring diagram for the component.step lamp, which is found in the car Infiniti G37 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram step lamp (1 of 1)
19 4 13 PPL ROOM LAMP CTRL PWR SPLY GND
89 90 91 60 PNK PUSH SW CAN-L CAN-H WIRE
BAT (F/L)
BAT FUSE
BCM (BODY CONTROL MODULE) (BEHIND RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR
DOOR ON
DRIVER SIDE DOOR SWITCH
DRIVER SIDE STEP LAMP
DRV DOOR SW
FUSE 10
FUSE 9 (J/B) (BEHIND LEFT KICK PANEL)
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE, FUSIBLE FUSIBLE LINK K LINK BLOCK
KEY BAT SLOT
KEY GND SW
KEY SLOT SW
LEFT VANITY MIRROR LAMP
LID LOCK ASSEMBLY)
LT BLU WIRE
LT GRN WIRE
OFF
P/W SW, RHT C/U COMM
PASS DOOR SW
PASSENGER SIDE DOOR SWITCH
PASSENGER SIDE STEP LAMP
PNK TRUNK LAMP OUT WIRE
PNK WIRE
PPL
PUSH BUTTON IGNITION SWITCH
PUSH SWITCH
REAR SIDE FINISHER)
RED WIRE
RETRACTABLE HARD TOP CONTROL UNIT (BEHIND LEFT
RIGHT VANITY MIRROR LAMP
ROOM LAMP
STEP LAMP
TAN WIRE
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH (INTEGRAL TO TRUNK
TRUNK SW
W/ STEERING LOCK UNIT
W/O STEERING LOCK UNIT
WHT WIRE
Go to component -> Courtesy lamps circuit, convertible -> STEP LAMP
