Infiniti G37 IV facelift (2006-2013) rf woofer Wiring diagrams

This page contains all the electrical diagrams for the component. rf woofer, in which he is found in the car Infiniti G37 IV facelift (2006-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rf woofer (1 of 4)

Wiring diagram rf woofer for Infiniti G37 IV facelift (2006-2013) (1 of 4)

Get access

AMP ON SIG BATTERY BLK WIRE BLU WIRE BOSE AMPLIFIER (LEFT SIDE OF LUGGAGE COMPT) BRN WIRE CENTER SPEAKER GRN WIRE GRY WIRE LEFT DOOR SQUAWKER LEFT DOOR WOOFER LEFT REAR SPEAKER LEFT REAR WOOFER LEFT TWEETER LF SOUND SIG (-) LF WOOFER LR DOOR SIG (+) LR SOUND SIG (-) LR WOOFER (+) LT BLU WIRE LT GRN WIRE MODE CHANGE SIG ORG/ WIRE PNK SHIELD WIRE PNK WIRE PPL RED WIRE RF SOUND SIG (-) RF WOOFER RIGHT DOOR SQUAWKER RIGHT DOOR WOOFER RIGHT REAR SPEAKER RIGHT REAR WOOFER RIGHT TWEETER RR DOOR SIG (-) RR SOUND SIG (-) RR WOOFER (+) SHIELD SIG CENTER (+) SIG WOOFER (+) SOUND SIG (-) TAN WIRE WHT WIRE WOOFER AMP ON SIG WOOFER AMP SIG WOOFER AMPLIFIER YEL WIRE

Go to component -> Bose radio circuit, coupe without navigation (3 of 4) -> RF WOOFER

Wiring diagram rf woofer (2 of 4)

Wiring diagram rf woofer for Infiniti G37 IV facelift (2006-2013) (2 of 4)

Get access

AMP ON SIG BATTERY BLK WIRE BLU WIRE BOSE AMPLIFIER (COUPE: LEFT SIDE OF LUGGAGE COMPT) BRN WIRE CENTER SIG CENTER SPEAKER COUPE, SEDAN GRN WIRE GRY WIRE LEFT FRONT DOOR SQUAWKER LEFT FRONT DOOR WOOFER LEFT REAR DOOR SPEAKER LEFT TWEETER LF SOUND SIG (-) LF WOOFER LR SOUND SIG (-) LT BLU WIRE LT GRN WIRE MODE CHANGE SIG ORG/ WIRE PNK WIRE PPL PPL COUPE PPL SEDAN RED WIRE RF SOUND SIG (-) RF WOOFER RIGHT FRONT DOOR SQUAWKER RIGHT FRONT DOOR WOOFER RIGHT REAR DOOR SPEAKER RIGHT TWEETER RR SOUND SIG (-) SHIELD SOUND SIG WFR (-) TAN WIRE WHT WIRE WOOFER AMP SIG YEL WIRE

Go to component -> Bose radio circuit, except convertible with navigation (2 of 4) -> RF WOOFER

Wiring diagram rf woofer (3 of 4)

Wiring diagram rf woofer for Infiniti G37 IV facelift (2006-2013) (3 of 4)

Get access

AMP ON SIG BATTERY BLK WIRE BLU WIRE BOSE AMPLIFIER (UNDER LEFT SIDE OF REAR PARCEL SHELF) BRN WIRE CENTER SPEAKER GRN WIRE GRY WIRE LEFT FRONT DOOR SQUAWKER LEFT FRONT DOOR WOOFER LEFT REAR DOOR SPEAKER LEFT TWEETER LF SOUND SIG (-) LF WOOFER LR DOOR SIG (+) LR SOUND SIG (-) LT BLU WIRE LT GRN WIRE MODE CHANGE SIG ORG/ WIRE PNK PNK WIRE PNK SHIELD WIRE PNK WIRE PPL RED WIRE RF SOUND SIG (-) RF WOOFER RIGHT FRONT DOOR SQUAWKER RIGHT FRONT DOOR WOOFER RIGHT REAR DOOR SPEAKER RIGHT TWEETER RR DOOR SIG (-) RR SOUND SIG (-) SHIELD SIG CENTER (+) SIG WOOFER (+) SOUND SIG (-) TAN WIRE WHT WIRE WOOFER WOOFER AMP ON SIG WOOFER AMP SIG YEL WIRE

Go to component -> Bose radio circuit, sedan without navigation (3 of 4) -> RF WOOFER
