Infiniti G37 IV facelift (2006-2013) retained acc power reverse signal Wiring diagram
This page shows the only wiring diagram for the component.retained acc power reverse signal, which is found in the car Infiniti G37 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram retained acc power reverse signal (1 of 1)
18 19 PNK WIRE
28 29 PPL
BEHIND REAR SEATS)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER SYSTEM
FUSE 10 FUSE 6
FUSE 14
FUSE 15
FUSE BLOCK (J/B) (BEHIND LEFT
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK I
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSIBLE LINK HOLDER (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK O
HOT W/ REAR WINDOW DEFOGGER RELAY ENERGIZED
KICK PANEL)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK PPL WIRE
PNK WIRE
POWER WINDOWS SYSTEM
POWER WINDOWS SYSTEM COMPUTER DATA LINES SYSTEM SOUND SYSTEMS
PPL
PPL 84 83
RECTRACTABLE HARD TOP CONTROL UNIT (BEHIND LEFT REAR SIDE FINISHER)
RED WIRE
RETAINED ACC POWER REVERSE SIGNAL
ROOF STATUS SENSOR (BEHIND LEFT REAR SIDE FINISHER)
ROOF WARNING BUZZER (BEHIND LEFT REAR SIDE FINISHER)
TAN WIRE
TONNEAU BOARD SWITCH (BEHIND LEFT TRUNK ROOM TRIM CAP)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit, convertible (1 of 3) -> RETAINED ACC POWER REVERSE SIGNAL
