Infiniti G37 IV facelift (2006-2013) r-ang sub sig can-l Wiring diagram

11 12 F-MTR PWR SPLY F-MTR GND 3 5 PNK WIRE 35 14 CAN-H CAN-L PNK WIRE 45 25 39 37 BUS-H BUS-L 55 71 56 72 54 53 GND GND CAN-H CAN-L BAT IGN 6 3 BUS-H BUS-L 7 27 COMM (METER) COMM (AMP) ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (LEFT REAR OF ENGINE COMPT) ACTUATOR BLK WIRE BLU WIRE BRN WIRE BUS-H BUS-L IGN CAN L CAN-H COMBINATION METER COMM (AMP) COMM (METER) COMPUTER DATA LINES SYSTEM CONTROL UNIT (LEFT SIDE OF LUGGAGE COMPT) CRUISE CONTROL SYSTEM FUSE 11 FUSE 3 (J/B) (BEHIND LEFT KICK PANEL) FUSE 37 FUSE BLOCK FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK I GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN LOCK SOL VCC LT BLU WIRE LT GRN WIRE MOTOR (UNDER REAR OF VEHICLE) NOISE SUPPRESSOR (LEFT SIDE OF TRUNK) P/S SOL R-MTR PWR SPLY RIGHT R-MTR LEFT R-MTR R-MTR GND PNK WIRE PNK WIRE POWER STEERING SOLENOID VALVE PPL R-ANG GND R-ANG VCC R-ANG MAIN SIG R-ANG SUB SIG CAN-L R-MTR RLY REAR MOTOR RELAY (LEFT REAR OF LUGGAGE COMPT) REAR WHEEL STEERING ANGLE SENSOR (LEFT SIDE OF TRUNK) RED WIRE TAN WIRE WHT WIRE YEL WIRE
