Infiniti G37 IV facelift (2006-2013) air computer conditioning data lines system system Wiring diagram
This page shows the only wiring diagram for the component.air computer conditioning data lines system system, which is found in the car Infiniti G37 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air computer conditioning data lines system system (1 of 1)
1 2 3 PPL
1 2 3 PPL 83 84 85
114 113 107 105 112 CAN-H CAN-L AVCC-PDPRES PDPRES GNDA PNK WIRE
A/C RELAY
AIR COMPUTER CONDITIONING DATA LINES SYSTEM SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN CONTROL MODULE (FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 1 (FRONT OF
COOLING FAN MOTOR 2 (FRONT OF
COOLING FAN RELAY (RIGHT REAR OF ENGINE COMPT)
COUPE 71 84 TW
ENGINE COMPT)
ENGINE CONTROL MODULE (ECM) (UNDER RIGHT END OF DASH)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
FUSE 42
FUSE 49
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK F
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION RELAY
NCA WIRE
PNK PPL (OR WIRE
PPL
RED WIRE
REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> AIR COMPUTER CONDITIONING DATA LINES SYSTEM SYSTEM
