Power top/sunroof circuit, sedan for Infiniti G35 III (2002-2007)

1 2 3 4 5 6 TILT UP/SLIDE CLOSE TILT DOWN/SLIDE OPEN 39 40 CAN-H CAN-L PNK WIRE 52 55 GND BAT BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BODY CONTROL MODULE (BEHIND LEFT KICK PANEL) CLOSED OPEN COMBINATION METER DOOR SW (DR) DRIVER SIDE FRONT DOOR SWITCH FUSE 1 FUSE 19 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPARTMENT) FUSIBLE LINK F GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGN PASSENGER SIDE FRONT DOOR SWITCH PNK 5 4 WIRE PNK COMPUTER DATA LINES SYSTEM WIRE PNK DOOR SW (AS) WIRE PNK WIRE POWER POWER GROUND PWR SUPPLY RED WIRE SUN ROOF MOTOR ASSEMBLY (AT CENTER FRONT OF ROOF) SUN ROOF SWITCH TILT DOWN/ SLIDE OPEN TILT UP/ SLIDE CLOSE UNIFIED METER CONTROL UNIT WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
