Exterior lamps circuit, sedan for Infiniti G35 III (2002-2007)

42 55 46 45 52 BAT (FUSE) BAT (F/L) RT FLASH OUT LT FLASH OUT GND BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) COMBINATION METER COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 14 FUSE 18 FUSE 19 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 6 FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HAZARD SWITCH HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START ILLUMINATION ON LEFT TURN IND LT GRN WIRE OFF PNK 3 4 WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE REMOTE KEYLESS ENTRY RECEIVER (W/O INTELLIGENT KEY) (BEHIND RIGHT SIDE OF DASH) RIGHT TURN IND UNIFIED METER CONTROL UNIT WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE CAN-L CAN-H CPU TAIL/LAMP RLY FUSE 71 FUSE 78 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 20 GND (SIGNAL) GND POWER GRN WIRE GRN/WHT WIRE HIGH MOUNTED STOPLAMP HIGH MOUNTED STOPLAMP LAMP HOT AT ALL TIMES LEFT FRONT COMBINATION LAMP LEFT FRONT SIDE MARKER LAMP LEFT LICENSE PLATE LEFT REAR COMBINATION LAMP PARKING PNK 3 4 WIRE PNK WIRE PNK/BLU WIRE PPL PPL/WHT WIRE RED WIRE RED/BLU WIRE RIGHT FRONT COMBINATION LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT LICENSE PLATE LAMP RIGHT REAR COMBINATION LAMP SIDE MARKER SIDE MARKER TURN STOP LAMP IN THE REAR AIR SPOILER STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) TAIL STOP TAILLAMP RELAY TURN W/ HIGH MOUNTED W/ HIGH MOUNTED STOP LAMP IN THE REAR PARCEL SHELF WHT WIRE YEL WIRE
