Exterior lamps circuit, coupe for Infiniti G35 III (2002-2007)

42 55 46 45 52 BAT (FUSE) BAT (F/L) RT FLASH OUT LT FLASH OUT GND BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) BUZZER COMBINATION METER COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 14 FUSE 18 FUSE 19 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HAZARD SWITCH HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START LEFT FRONT COMBINATION LAMP LEFT TURN IND LT GRN WIRE OFF ON ILLUMINATION PARKING PNK 3 4 WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE RED/BLU WIRE RIGHT FRONT COMBINATION LAMP RIGHT TURN IND TURN SIGNAL UNIFIED METER CONTROL UNIT WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

+IG B+ B- BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE CAN L CPU TAIL/LAMP RLY FUSE 20 FUSE 71 FUSE 78 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) GND (POWER) CAN-H GND (SIGNAL) GRN WIRE GRN/WHT WIRE HIGH MOUNTED STOPLAMP HOT AT ALL TIMES HOT IN ON OR START IGNITION RELAY LAMP LEFT FRONT SIDE MARKER LAMP LEFT LICENSE PLATE LEFT REAR COMBINATION LAMP LT GRN WIRE PNK 3 4 WIRE PNK PPL WIRE PNK WIRE PNK/BLU WIRE PPL/WHT WIRE RED WIRE RED/BLU WIRE RIGHT FRONT SIDE MARKER LAMP RIGHT LICENSE PLATE LAMP RIGHT REAR COMBINATION LAMP SIDE MARKER SIDE MARKER TURN STOP LAMP IN THE REAR AIR SPOILER STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) TAIL STOP TAILLAMP RELAY TURN W/ HIGH MOUNTED W/ HIGH MOUNTED STOP LAMP IN THE REAR PARCEL SHELF WHT WIRE YEL WIRE
