Wiring diagram engine performance 3.5l, coupe for Infiniti G35 III (2002-2007)

A/T ASSEMBLY TCM (TRANSMISSION CONTROL MODULE) AVCC AVCC BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE C-IVC (L) C-IVC (R) PS PRES POS PHASE LH COMBINATION METER CONDENSER (RIGHT REAR OF ENGINE) CRANKSHAFT POSITION SENSOR (POS) (ON FRONT OF OIL PAN, BELOW CRANKSHAFT PULLEY) ENGINE CONTROL MODULE (BEHIND GLOVE BOX) EVAP FUEL INJECTOR GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE INJ 5 INJ 3 INJ 1 KNOCK SENSOR (TOP CENTER FRONT OF ENGINE) NCA WIRE NEUTRAL ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH (REAR OF TRANS- MISSION) PNK FTRPS PHASE RH TA WIRE PNK INJ 6 INJ 4 INJ 2 WIRE PNK WIRE PNK/BLK WIRE PPL/RED WIRE QA+ RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE REFRIGERANT PRESSURE SENSOR (ON A/C LIQUID TANK) UNIFIED METER CONTROL UNIT V MOT WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE

24 25 PNK WIRE 36 37 PNK WIRE BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE ECM RELAY ELECTRIC THROTTLE CONTROL ACTUATOR (ON THROTTLE BODY ASSEMBLY) FUEL PUMP RELAY FUSE 81 FUSE 87 FUSE 77 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION COIL 1 (W/ POWER TRANSISTOR) IGNITION COIL 2 (W/ POWER TRANSISTOR) IGNITION COIL 3 (W/ POWER TRANSISTOR) IGNITION COIL 4 (W/ POWER TRANSISTOR) IGNITION COIL 5 (W/ POWER TRANSISTOR) IGNITION COIL 6 (W/ POWER TRANSISTOR) INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM (RIGHT REAR OF ENGINE COMPT) NCA WIRE ORG/ WIRE PLUG SPARK PNK 16 17 18 19 20 21 WIRE PNK WIRE PNK/BLK WIRE PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SPARK PLUG THROTTLE CONTROL MOTOR RELAY THROTTLE CONTROL MOTOR THROTTLE POSITION (TP) SENSOR 2 THROTTLE POSITION (TP) SENSOR 1 WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

26 27 PNK WIRE 36 37 PNK WIRE AIR FUEL RATIO SENSOR 1 (BANK 1) (AT TOP RIGHT OF ENGINE) AIR FUEL RATIO SENSOR 1 (BANK 2) (AT TOP LEFT OF ENGINE) BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CAMSHAFT POSITION SENSOR (PHASE) (BANK 1) (RIGHT REAR OF ENGINE) CAMSHAFT POSITION SENSOR (PHASE) (BANK 2) ENGINE COOLANT TEMPERATURE SENSOR (ON TOP RIGHT REAR OF ENGINE) EVAP CONTROL SYSTEM PRESSURE SENSOR (UNDER VEHICLE, NEAR EVAP CANISTER) FUSE 85 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HOT IN ON OR START INTAKE VALVE TIMING CONTROL SOLENOID VALVE (BANK 1) (ON RIGHT FRONT OF ENGINE) INTAKE VALVE TIMING CONTROL SOLENOID VALVE (BANK 2) (ON LEFT FRONT OF ENGINE) INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM (RIGHT REAR OF ENGINE COMPT) MASS AIRFLOW (MAF) SENSOR (ON INTAKE AIR DUCT HOUSING) ORG/ WIRE PNK WIRE PNK/BLK WIRE PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

A/T ASCDSW AVCC BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE NEUT BRN WIRE BRN/YEL WIRE CAN-H COMPUTER DATA LINES SYSTEM CONDENSER (FORWARD OF LEFT REAR WHEELWELL) CRUISE CONTROL SYSTEM ENGINE CONTROL MODULE (BEHIND GLOVE BOX) EVAP CANISTER VENT CONTROL VALVE (ON EVAP CANISTER) FPR FUEL LEVEL SENSOR UNIT, FUEL PUMP (IN FUEL TANK) FUSE 1 FUSE 20 FUSE 34 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR OF ENGINE COMPT) GND 02 IGN 6 IGN 4 IGN 2 GND A GND A AVCC GND GND CDCV GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START IGN 5 IGN 3 IGN 1 LT BLU WIRE LT GRN/BLK WIRE M/T MOTRLY PDPRES PNK VB VB BATT WIRE PNK WIRE PNK/BLU WIRE POWER STEERING PRESSURE SENSOR (ON POWER STEERING HIGH PRESSURE TUBE) PPL DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) PPL PNK KLINE CAN L WIRE PPL/WHT WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SENSOR 1 SENSOR 2 ACCELERATOR PEDAL POSITION (APP) SENSOR (ON ACCELERATOR PEDAL BRACKET) SSOFF STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) TF BNCSW IGN SW WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
