Infiniti G35 III (2002-2007) w/ intelligent key Wiring diagrams
This page contains all the electrical diagrams for the component. w/ intelligent key, in which he is found in the car Infiniti G35 III (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ intelligent key (1 of 3)
BELT IND
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN WIRE
BUZZER
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
DOOR IND
DOOR SW (DR)
DRIVER SEAT BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE)
DRIVER SIDE FRONT DOOR SWITCH
FUSE 1
FUSE 14
FUSE 19
FUSE 21
FUSE 33
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK F
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
KEY SWITCH
LT BLU WIRE
PPL
RED WIRE
UNIFIED METER CONTROL UNIT
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Chime circuit -> W/ INTELLIGENT KEY
Wiring diagram w/ intelligent key (2 of 3)
55 41 47 48 52 BAT (F/L) BAT SAVER OUT STEP LAMP OUT ROOM LAMP OUT GND
64 62 63 57 TRUNK LAMP OUT DOOR SW (DR) DOOR SW (RR LH) TRUNK SW
BLK WIRE
BLK/PNK WIRE
BLU WIRE
DIODE
DOOR
DRIVER SIDE FRONT DOOR SWITCH
DRIVER SIDE STEP LAMP
FUSE 1
FUSE 21
FUSE 33
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY HOLE ILLUMINATION
KEY SWITCH
KEY SWITCH, IGNITION KNOB SWITCH
LEFT PERSONAL LAMP
LEFT REAR DOOR SWITCH
MAP LAMP
OFF
OFF DRIVER VANITY MIRROR LAMP (IF EQUIPPED)
OFF RIGHT VANITY MIRROR LAMP (IF EQUIPPED)
ON DOOR
ON ON OFF
PASSENGER SIDE FRONT DOOR SWITCH
PASSENGER SIDE STEP LAMP
PNK WIRE
POWER WINDOWS SYSTEM COMPUTER DATA LINES SYSTEM
PPL
PPL PNK PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT PERSONAL LAMP
RIGHT REAR DOOR SWITCH
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH (AT REAR CENTER OF TRUNK)
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/PPL WIRE
Go to component -> Courtesy lamps circuit, sedan -> W/ INTELLIGENT KEY
Wiring diagram w/ intelligent key (3 of 3)
A/T DEVICE (PARK POSITION SWITCH) (UNDER CENTER CONSOLE)
A/T M/T
ADP STEERING SWITCH
BAT (PTC) GND (SIGNAL) GND (SENSOR) TILT MOTOR (DN)
BLK WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
FUSE 21 (BEHIND LEFT KICK PANEL)
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX (AT RIGHT REAR OF ENGINE COMPT) FUSE 33
GND POWER
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IND 2 MEMORY
INSTRUMENT CLUSTER SYSTEM
LT GRN WIRE
LT GRN/BLK WIRE
MEMORY IND 1
ON OFF CANCEL SW
ON ON ON OFF OFF OFF SET
ORG/BLU WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK/BLK WIRE
PNK/BLU WIRE
PPL/RED WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RX TELESCOPIC SW (BACK)
SEAT MEMORY SWITCH
SENSOR TILT
TELES- COPIC SW
TELESCOPIC MOTOR
TELESCOPIC MTR (BACK)
TELESCOPIC SENS
TELESCOPIC SENSOR
TILT MOTOR 2 1
TILT SENSOR
TILT SW
TILT SW (DOWN)
TX TELESCOPIC SW (FWD)
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Memory systems circuit (1 of 2) -> W/ INTELLIGENT KEY
