Infiniti G35 III (2002-2007) tire pressure warning check switch Wiring diagram
This page shows the only wiring diagram for the component.tire pressure warning check switch, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tire pressure warning check switch (1 of 1)
1 4 2 GND POWER SIGNAL
38 39 40 20 19 18 15 IGN SW CAN-H CAN-L SIGNAL PWR KEYLESS TPMS MODE TRIGGER SW
52 55 42 GND BAT (F/L) BAT (FUSE)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BUZZER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 18
FUSE 19
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 14
FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
PNK WIRE
RED WIRE
RED/WHT WIRE
REMOTE KEYLESS ENTRY RECEIVER (BEHIND RIGHT SIDE OF DASH)
TIRE PRESSURE IND
TIRE PRESSURE WARNING CHECK SWITCH
UNIFIED METER CONTROL UNIT
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> TIRE PRESSURE WARNING CHECK SWITCH
