Infiniti G35 III (2002-2007) switch seek Wiring diagram
This page shows the only wiring diagram for the component.switch seek, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch seek (1 of 1)
5 6 7 8 9 10 ANT SIG BAT (BACK-UP) ILLUMI CONTROL LIGHT SW
ANTENNA (SUB) ANT SIG
ANTENNA AMPLIFIER (AT LEFT "C" PILLAR)
AUDIO UNIT
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH
DOWN
FEEDER CABLE
FUSE 37
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BOX
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
ILLUM
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LH FR SP (+)
LH RR SP (-) LH RR SP (+) RH RR SP (-) RH RR SP (+)
LT GRN WIRE
NCA WIRE
OFF
OPTION CONNECTOR FOR AUDIO UNIT
OPTION CONNECTOR FOR SATELLITE RADIO RECEIVER (USA)
ORG/ WIRE
ORG/BLU WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
REM CNTRL GND
REM CONTROL A REM CONTROL B
RH FR SP (+)
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
SPEED SIGNAL
STEERING WHEEL/ AUDIO CONTROL SWITCH
SWITCH MODE
SWITCH POWER
SWITCH SEEK
SWITCH VOLUME
UNIFIED METER CONTROL UNIT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WINDOW ANTENNA
WINDOW ANTENNA (SUB)
YEL WIRE
Go to component -> Radio circuit, sedan with base audio -> SWITCH SEEK
