Infiniti G35 III (2002-2007) right personal lamp Wiring diagram
This page shows the only wiring diagram for the component.right personal lamp, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right personal lamp (1 of 1)
55 41 47 48 52 BAT (F/L) BAT SAVER OUT STEP LAMP OUT ROOM LAMP OUT GND
64 62 63 57 TRUNK LAMP OUT DOOR SW (DR) DOOR SW (RR LH) TRUNK SW
BLK WIRE
BLK/PNK WIRE
BLU WIRE
DIODE
DOOR
DRIVER SIDE FRONT DOOR SWITCH
DRIVER SIDE STEP LAMP
FUSE 1
FUSE 21
FUSE 33
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY HOLE ILLUMINATION
KEY SWITCH
KEY SWITCH, IGNITION KNOB SWITCH
LEFT PERSONAL LAMP
LEFT REAR DOOR SWITCH
MAP LAMP
OFF
OFF DRIVER VANITY MIRROR LAMP (IF EQUIPPED)
OFF RIGHT VANITY MIRROR LAMP (IF EQUIPPED)
ON DOOR
ON ON OFF
PASSENGER SIDE FRONT DOOR SWITCH
PASSENGER SIDE STEP LAMP
PNK WIRE
POWER WINDOWS SYSTEM COMPUTER DATA LINES SYSTEM
PPL
PPL PNK PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT PERSONAL LAMP
RIGHT REAR DOOR SWITCH
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH (AT REAR CENTER OF TRUNK)
W/ INTELLIGENT KEY
W/O INTELLIGENT KEY
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/PPL WIRE
Go to component -> Courtesy lamps circuit, sedan -> RIGHT PERSONAL LAMP
