Infiniti G35 III (2002-2007) pnp sw or gnd Wiring diagram
This page shows the only wiring diagram for the component.pnp sw or gnd, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnp sw or gnd (1 of 1)
A/T
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CPU B+
FUSE 71
FUSE 78
FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPARTMENT)
FUSIBLE LINK M
GND (SIGNAL)
GND POWER
GRN/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
IGNITION SWITCH
M/T
NCA WIRE
PNP SW OR GND
RED WIRE
START RLY
STARTER
STARTER MOTOR
STARTER RELAY
TCM A/T ASSEMBLY (AT REAR OF ENGINE COMPARTMENT)
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Starting circuit -> PNP SW OR GND
