Infiniti G35 III (2002-2007) pnk interior trunk switch pnk can-l Wiring diagrams
This page contains all the electrical diagrams for the component. pnk interior trunk switch pnk can-l, in which he is found in the car Infiniti G35 III (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk interior trunk switch pnk can-l (1 of 2)
BAT (F/L)
BAT FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
CAN-H
CANCEL SW INPUT
COMPUTER DATA LINES SYSTEM
FUSE
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK F
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
ILLUM
INTELLIGENT KEY UNIT (BEHIND RIGHT SIDE OF DASH)
PNK INTERIOR TRUNK SWITCH PNK CAN-L WIRE
PNK WIRE
RED/BLU WIRE
RED/YEL WIRE
TRUNK LID OPENER ACTUATOR (AT REAR CENTER OF TRUNK)
TRUNK LID OPENER CANCEL SWITCH
TRUNK LID OPENER SWITCH
TRUNK OPENER OUTPUT
WHT/RED WIRE
Go to component -> Trunk release circuit, sedan with intelligent key unit -> PNK INTERIOR TRUNK SWITCH PNK CAN-L WIRE
Wiring diagram pnk interior trunk switch pnk can-l (2 of 2)
BAT (F/L)
BAT FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK F (AT RIGHT REAR OF ENGINE COMPARTMENT)
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
ILLUM
KEYLESS TUNER POWER SUPPLY
KEYLESS TUNER SIGNAL
OUTSIDE TRUNK LID OPENER SWITCH (LEFT REAR OF TRUNK)
PNK INTERIOR TRUNK SWITCH PNK CAN-L WIRE
PNK WIRE
RED WIRE
REMOTE KEYLESS ENTRY RECEIVER (BEHIND RIGHT SIDE OF DASH)
SENSOR GND
TRUNK LID OPENER ACTUATOR (AT REAR CENTER OF TRUNK)
TRUNK LID OPENER CANCEL SWITCH
TRUNK LID OPENER SWITCH
TRUNK OPENER OUTPUT
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Trunk release circuit, sedan without intelligent key unit -> PNK INTERIOR TRUNK SWITCH PNK CAN-L WIRE
